      What is an electric screen lift?

      An electric screen lift is a motorised system that automatically raises and lowers a screen or projector, including LCD, LED and plasma displays.

      Used in conference rooms, theatres, performance venues and event installations, an electric lift transforms the way visual displays are managed within a space by removing the constraints of manual handling.

      ALP Flight Cases designs and integrates custom electric lifts for every application: retractable conference table installations, stage screens descending from the fly tower, control monitors rising from furniture, and televisions emerging from designer cabinets.

      Every electric lift is designed as a complete solution, incorporating mechanics, control electronics and aesthetic finishes.

      Electric lifts: operation and benefits

      An electric lift uses an electric motor, either DC or AC depending on the power required, with a screw, rack-and-pinion or belt drive.

      It can be controlled by an RF remote control, a wired switch, DMX or a network control signal such as IP or RS232.

      Electric lifts offer numerous benefits:

      • No need to handle heavy screens manually
      • A discreet appearance: the screen disappears when not in use
      • Safety: the electric lift incorporates limit switches to prevent accidents
      • Precise position control

      Which screen types can use an electric lift?

      LCD/LED screen lifts

      An electric lift for LCD or LED screens is the most common configuration.

      Compatible with every flat-screen format from 24 to 110 inches, it can be integrated into a table hatch, floor enclosure or suspended structure. The maximum load supported by an ALP electric lift ranges from 15 to 100 kg, depending on the model.

      TV lifts

      An electric TV lift is used in hotels, restaurants, reception venues and corporate spaces to reveal or conceal a television as needed.

      This TV lift solution combines functionality and aesthetics, adapting to the architectural requirements of each installation.

      Where can an electric screen lift be used?

      Electric lifts are suited to many settings:

      • Meeting rooms and corporate spaces: presentation screens that retract into conference tables
      • Stages and TV studios: monitors and teleprompters that lower automatically for rehearsals
      • Hotels and restaurants: televisions integrated into furniture or designer columns
      • Museums and exhibitions: interactive screens that rise to visitor height
      • Theatres and opera houses: surtitling screens and motorised signage panels

      In each of these settings, an electric lift offers a more elegant, safer and more practical solution than traditional manual systems.

      These screen lifts are often combined with our screen flight cases for a complete transport and installation solution.

      To protect your video equipment, also explore our video flight cases and video equipment covers.

      How to choose your electric lift

      Maximum load capacity

      The electric lift's load capacity must be at least 20% greater than the weight of the screen being lifted.

      ALP offers electric lifts with capacities from 15 kg for small desktop screens to 150 kg for large stage screens. The load includes the screen, its mount and integrated cables.

      Travel and lifting speed

      Travel is the vertical distance between the lower, retracted position and the upper, extended position.

      An ALP electric lift offers travel distances from 200 mm to 1500 mm, depending on the model. Lifting speed generally ranges from 10 to 50 mm/second, depending on the load and motor system.

      Controls and operation: remote control, DMX and more

      An ALP electric lift can be operated by RF remote control, wired switch, DMX interface, the standard protocol in live entertainment, or IP network control.

      DMX control is particularly popular in stage installations where the electric lift needs to be synchronised with other stage automation systems.

      ALP: manufacturer and integrator of custom electric lifts

      ALP designs and integrates custom electric lifts from initial design through to commissioning.

      Our engineering team supports every project from specification to on-site installation, including design, manufacture and testing.

      Every ALP electric lift is CE-certified and supplied with complete technical documentation.

      FAQ: Electric lifts and screen lifts

      What is the maximum load an electric screen lift can raise?

      ALP electric lifts support loads from 15 to 150 kg, depending on the model. For specific load requirements, contact our design team for a custom solution.

      What is the difference between an electric lift and a conventional motorised mount?

      An electric lift moves the screen vertically over a defined travel distance. A motorised mount adjusts the screen's tilt or rotation angle without significant vertical movement.

      Can an electric lift be operated remotely or via DMX?

      Yes, an ALP electric lift can be supplied with built-in DMX control as an option for complete integration into stage automation systems. IP control via OSC or TCP/IP is also available.

      How much noise does an electric lift make during operation?

      A well-designed electric lift operates at less than 45 dB(A) at 1 metre, making it discreet during presentations and performances. Quiet models with brushless DC motors operate below 35 dB(A).
